One PDF at a time

The parser is Rust, #![forbid(unsafe_code)], and it crashed with SIGTRAP. Then, after the obvious fix, it segfaulted instead.

Neither crash is in Rust. Both are in pdfium — Chrome’s PDF library, reached through pdfium-render. The forbid attribute is doing exactly what it promises: there is no unsafe code in this crate. It says nothing about the C++ library on the other side of the FFI boundary, and that library has two independent threading rules that are not in any signature.

Crash one: one instance per document

The natural Rust shape is for each document to own its resources:

struct Pdf { pdfium: Pdfium, /* ... */ }   // one library handle per document

That is how you would model almost anything else. It is wrong here, and it does not fail gracefully — it SIGTRAPs the moment two instances exist. pdfium sets up and tears down process-global state per Pdfium instance, so a second instance’s initialisation walks over the first one’s world.

So the handle is a process singleton:

static PDFIUM: OnceLock<Pdfium> = OnceLock::new();

Pdf then holds only the document bytes. It is a document that knows how to ask the one library for its pages, rather than a document that owns a library.

Crash two: one call at a time

With a single shared instance the SIGTRAP goes away, and you get a segfault instead, because pdfium is not safe for concurrent document work even from one instance. Two threads calling extract_pages on two different documents will eventually corrupt each other.

There is no way to make that safe from the Rust side except by not doing it:

static PDFIUM_GUARD: Mutex<()> = Mutex::new(());

/// Serializes pdfium access. Recovers from poisoning: the lock protects a C library,
/// not our invariants, so a panicking caller does not corrupt what we guard.
fn pdfium_guard() -> MutexGuard<'static, ()> {
    PDFIUM_GUARD
        .lock()
        .unwrap_or_else(|poisoned| poisoned.into_inner())
}

Every pdfium call in the process takes that guard. It is a Mutex<()> — it guards nothing of ours, it guards the library, which is why the poison recovery is correct here and would be suspicious anywhere else. A panic while holding it means a caller’s parse blew up; it does not mean pdfium’s internal state is now inconsistent in a way that a second caller must be protected from. Poisoning would just convert one failed document into every subsequent document failing.

The consequence you have to design around

Once that mutex exists, PDF work in a process is strictly serial. No amount of rayon or tokio changes it — you can spawn eight tasks and they will queue at the lock.

Two things follow, and they’re the actual engineering:

Scale with processes, not threads. The unit of parallelism for ingestion is the OS process. That is a deployment shape, not a code change, and it needs to be decided early because it determines how work is distributed and how memory is budgeted.

Keep everything else outside the guard. Model inference is the expensive part of this pipeline, and it must not run while holding the pdfium lock. The guard covers page extraction and nothing else; the moment the pages are out of pdfium, the lock is released and the slow, parallel-friendly work happens outside it. Get that wrong and you have serialised the whole pipeline behind a library that only needed the first stage.

The constraint is one call at a time. The design question is how little work you can do while holding it.

The test that has to exist

A constraint you cannot see in a type signature needs a test that fails loudly when someone removes it — and the natural refactor here (“why is this a singleton? why is there a global lock?”) is exactly the one a well-meaning reviewer proposes:

#[test]
fn concurrent_extraction_does_not_crash() {
    let bytes = fixtures::text_pdf("CLAIM 12345 PAID 1,000.00");
    let handles: Vec<_> = (0..8)
        .map(|_| {
            let bytes = bytes.clone();
            std::thread::spawn(move || {
                let pdf = Pdf::from_bytes(&bytes).unwrap();
                let pages = pdf.extract_pages(72, DEFAULT_MIN_TEXT_CHARS).unwrap();
                assert_eq!(pages.len(), 1);
            })
        })
        .collect();
    for handle in handles {
        handle.join().expect("no thread may crash pdfium");
    }
}

Eight threads, one document, and an assertion that no thread died. It is not a subtle test. Its whole job is to turn “remove this weird global mutex” from a merge into a red build.

Note the fixture: a hand-built synthetic page, not a real document. The data/ directory in this repo holds actual client insurance documents and is gitignored, and the rule is absolute — never commit a customer document, a filename, or a carrier-identifying fixture. Which means every test PDF is constructed in code. That is more work up front and it is the only version of this test that can exist in a public repository.

The unglamorous part: making the library findable

pdfium is a shared library that has to be present at runtime, and the pinned build is a specific tag of pdfium-binaries referenced in two places — the runbook and the CI workflow — which must agree. A mismatch there is a runtime failure that looks like a code bug.

The search order is: PDFIUM_LIB_PATH from the environment, then the vendored directory in the repo, then the working directory. Failure is explicit and tells you what to do:

pdfium shared library not found (last error: …);
set PDFIUM_LIB_PATH or run scripts/fetch-pdfium.sh

Half the value of an FFI dependency’s error handling is in that second line. “Not found” is a puzzle; “not found, run this script” is a task.

What generalises

An FFI boundary imports the other library’s threading model, and that model is not in the signature. pdfium-render is safe Rust — safe in the borrow-checker sense — and both crashes above are things the compiler cannot see and will never warn you about.

So the rules that came out of this are:

1. Assume process-global until proven otherwise. A C library that initialises “the world” usually means one world per process.
2. Serialise first, optimise second. A global lock is a bad performance story and a fine correctness story. Ship the correct one, then move work out from under it.
3. Write down why the lock recovers from poisoning — otherwise it reads as sloppiness rather than a deliberate call about what is being protected.
4. Leave a test whose only purpose is to fail on the obvious refactor. The constraint is invisible; the test is the only thing that makes it real to the next reader.

#![forbid(unsafe_code)] at the top of the crate is still true, and still worth having. It just draws its boundary at the FFI edge, and everything past that edge is somebody else’s rules.
